STANDARD EQUIPMENT AND OPENING TYPOLOGIES RELUCE

AVAILABLE NEW SPECIAL OPENING TYPOLOGIES

READ MORE

FIXED

with glass stop
false profile with fixed hinges
  1. lucid flat yarn exceeded 2,5 m2 of glass part (for fixed with glass stop)
  2. new thermal spacer
  3. argon gas
  4. low emissive glass*

GLASSES FIXED WITH GLASS STOP (according to dimensions)

  • 4BE-22-6/7 (security glass)
  • 6/7-20-BE6/7 (security glass)
  • 8/9-18-BE8/9 (security glass)

GLASSES FIXED FALSE PROFILE (according to dimensions)

  • 4BE-18-6/7 (security glass)
  • 6/7-15-BE6/7 (security glass)

TRANSOM WINDOW

with upper central handle
  1. oversize profile
  2. handle with Secustik system (not forcing)
  3. new thermal spacer
  4. argon gas
  5. low emissive glass*

GLASSES (according to dimensions)

  • 4BE-18-6/7 (security glass)
  • 6/7-15-BE6/7 (security glass)

WINDOWS AND FRENCH WINDOWS

1 door
2 doors
3 doors
  1. handle with Secustick system (not forcing)
  2. one folding door (for windows and French windows one-two doors)
  3. two folding doors (for windows and French windows 3 doors)
  4. lever bolt on semi-fixed door (for windows and French windows two and three doors- H max 1200 mm)
  5. false manoeuvre system
  6. micro ventilation
  7. new thermal spacer
  8. argon gas
  9. low emissive glass*
  10. not forcing inferior
  11. reduced threshold with thermal cut with aluminium drip colored as profile (for French windows)

GLASSES

  • 4BE-18-6/7 (security glass)
  • 4BE-15-6/7 (security glass)

FRENCH WINDOW WITH LOCK

1 door
2 doors
3 doors
  1. two handles with Secustik system (not forcing)
  2. one multipoint lock with folding door (without click and without turns) and passing cylinder, false manoeuvre system, micro ventilation, inferior check not forcing (on typology with 2 doors for French windows 3 doors) in option multipoint lock (with click and without turns) and passing cylinder
  3. one folding door on typology with one door (for French windows 3 doors)
  4. one passing bolt on semi-fixed door (for French windows 3 doors)
  5. new thermal spacer
  6. micro ventilation
  7. new thermal spacer
  8. argon gas
  9. low emissive glass*
  10. reduced threshold thermal cut with aluminium drip colored as profile

GLASSES

  • 6/7BE-15-6/7 (security glass)

FRENCH WINDOW MAXI

intermediate profile – big size

1 door
2 doors
3 doors
  1. handle with Secustik system (not forcing)
  2. one passing bolt on semi-fixed door (for French windows 3 doors)
  3. new thermal spacer
  4. argon gas
  5. low emissive glass*
  6. reduced threshold thermal cut with aluminium drip colored as profile

GLASSES

  • 6/7BE-15-6/7 (security glass)

BASCULE

HORIZONTAL
  1. handle with Secustik system (not forcing)
  2. lucid flat yarn exceeded 2,5 m² of glass part
  3. micro ventilation
  4. new thermal spacer
  5. new thermal spacer
  6. argon gas
  7. low emissive glass*

GLASSES

  • 4BE-18-6/7 (security glass)
  • 6/7-15-BE6/7 (security glass)

TILT AND TURN SLIDING

fixed with glass stop
with one opening door
  1. oversize door (for that with one fixed door according to dimensions)
  2. lucid yarn profile exceeded 2,5 m² of glass part (for that with one fixed door according dimensions)
  3. semi-automatic or automatic mechanism (according to dimensions-capacity max 160 kg)
  4. new thermal spacer
  5. argon gas
  6. low emissive glass*

GLASSES (as dimensions)

  • 4BE-18-6/7 (security glass)
  • 6/7-15-BE6/7 (security glass)

LIFTING AND SLIDING

1 anta apribile e laterale fisso con fermavetro
  1. internal big handle and transport external basin
  2. lucid flat yarn profile exceeded 2,5 m2 of glass part
  3. new thermal spacer
  4. argon gas
  5. low emissive glass*

GLASSES (according to dimensions)

  • 4BE-20-6/7 (security glass)
  • 6/7-18-BE6/7 (security glass)
  • 8/9-12-BE8/9 (security glass)

ENTRANCE DOOR

1 door
2 doors
  1. multipoint lock with click, 2 turns included internal handle and passing security cylinder that has : flat reversible key, not drill plugs tempered, but in steel not rift, 7 little pistons for ciphering 5 sealed keys, paper for duplications, washer cover cylinder only internal
  2. adjustable hinges
  3. blade not cold
  4. new thermal spacer
  5. argon gas
  6. low emissive glass*

GLASSES (according to dimensions)

  • 6/7-15-BE6/7 (security glass)

DOOR WITH EXTERNAL OPENING

1 door
2 doors
  1. multipoint lock with click, 2 turns included internal handle and passing security cylinder that has: flat reversible key, not drill plugs tempered, but in steel not rift, 7 little pistons for ciphering 5 sealed keys, paper for duplications, washer cover cylinder only internal or in option panic push bar with 3 closing points
  2. adjustable hinges
  3. blade not cold
  4. new thermal spacer
  5. argon gas
  6. low emissive glass*

GLASSES (according to dimensions)

  • 6/7-15-BE6/7 (security glass)

*low emissive glass is insulating, characterized by 2 or more sheets spaced out by one or more spacer. Insulating glass is different from normal glass because is characterized by a particular treatment and thanks to it it’s possible to contain dispersions

SPECIAL FORMS

CURVED ALL SIXTH (only for flat profile)

Minimum ray of execution: fixed frame 450 mm.

fixed with glass stop

CURVED SIXTH REDUCED (only for flat profile)

Minimum ray of execution: fixed frame 450 mm.

fixed with glass stop

NOT STANDARD

Height minimum: fixed 200 mm, openable 350 mm.

fixed with glass stop
1 door
2 doors
3 doors

PORTHOLE

Diameter minimum: fixed frame 900 mm.

fixed with glass stop

NOTE:

  • Curves typologies COULDN’T BE MADE with laminate HF wood.
  • Prices presented are indicatives about their form of execution.
  • For preventives it is necessary to contact the Technical office for verifying practicability of opening typology.
  • For production of curved product, enterprise has to verify practicability only after seeing the profile of the same.
